HVCB-5100IV 5MP IR Bullet Network Camera
Honeywell HVCB-5100IV IR Bullet Net-work Camera, it combines with the world-class
imaging technology and cameras technology with innovative IP networking technology.
Provide users with 5MP high quality images.
The HVCB-5100IV IR Bullet Camera Network Camera is the ideal solution for ad-
vanced surveillance with its high-quality image quality. Built-in2.8-12mm MFZ
lens, it allows users to adjust the lens to the best angle according to site monitoring
environment.
HVCB-5100IVhas built-in IR. The maximum IR distance is 50 meters. Provide users
with clear black and white images in low light or all black environments.
The HVCB-5100IV supports PoE Ethernet(IEEE802.3af),which can directly supply
power to the network camera through the network cable, helping users to save the
use of the power adapter and effectively reduce the installation cost. To increase
the installation flexibility of the HVCB-5100IV, the network camera also supports
DC12V power supply.
Honeywell HVCB-5100IV support 5MPvideo,H.265 efficient compression, POE
Ethernet power supply and ONVIF network interface, it still can provide5MP real-
time video even in a limited bandwidth environment. Bullet appearance design
makes it the ideal choice all kinds of security, monitoring application, and widely
used in all kinds of indoor and outdoor venues, such as road, airports, schools,
shopping malls, hotels, and bank branches, enterprises and organs, retail stores,
building corridor, etc.
FEATURES
·1/2.7"Progressive Scan CMOS
·120dB WDR
IP66 protection
·Support2880x 1620@25fps
·Up to 50m IR distance ONVIF
·Support H.265/H.264/ MJPEG
2.8~12mm MFZ lens
·12VDC/PoE
SPECIFICATION
Model
HVCB-5100IV
Camera
Image Sensor
1/2.7"Progressive Scan CMOS
Min. Illumination
Color:0.007Lux@F1.4(AGC ON), B/W:0Lux(IR On)
Shutter Speed
1s~1/100.000s
Day/ Night
IR Cut Filter
S/N Ratio
50dB
WDR
120dB
Focal Length
2.8~12mm, MFZ lens
FOV
Horizontal 100°~ 36.5°, Vertical 52°~20.5°,Diagonal 116°~41°
Aperture
F1.4
IR Range
IR:30-50m
3-Axis Adjustment
Pan: 0°~ 360°, tilt: 0°~ 90°,rotation: 0°~360°
Audio & Video Codec
Video Compression
H.265/H.264/ MJPEG(Sub stream only)
Main Stream:25/30fps@2880x1620,2560x1440.2304x1296.1920*1080P.1280*720
Resolution
Sub Stream:25/30fps@1280x720.704x576.640x480.352*288
Third Stream:25/30fps@704* 576,640*480,352x288
H.265 Type
Main Profile
H.264 Type
Baseline Profile/ Main Profile/High Profile
Video Bit Rate
64Kbps~8Mbps
Audio & Video Function
Image Enhancement
BLC, HLC, DNR
Image Settings
Image rotation,saturation, brightness, contrast, sharpness, corridor mode
ROI
Independent settings for each stream
Video Analysis
Object Abandoned/ Missing, Video Exception, Line Crossing,Region Intrusion
