NDE-3703-AL Fixed dome 5MP 3.3-10.2mm IP66 IK10 IR
Commercial Type No.: NDE-3703-AL | Product No.: F.01U.406.612
FLEXIDOME OUTDOOR 3100I IR
5 MP for highly detailed images
IVA Pro Buildings brings reliable deep-learning based detection of persons and vehicles
High Dynamic Range (HDR) to see every detail in both bright and dark areas of the scene
Built-in Secure Element with Trusted Platform Module (TPM) to ensure the highest level of security for device access and data transport
Built-in IR illuminator with up to 30 m (98 ft) viewing distance
NDE-3703-AL-IO Dome 5MP 3.3-10.2mm IP66 IK10 IR I/O
Commercial Type No.: NDE-3703-AL-IO | Product No.: F.01U.427.710
5 MP for highly detailed images
IVA Pro Buildings brings reliable deep-learning based detection of persons and vehicles
Alarm and audio inputs and outputs
Built-in Secure Element with Trusted Platform Module (TPM) to ensure the highest level of security for device access and data transport
Built-in IR illuminator with up to 30 m (98 ft) viewing distance
NDE-3703-AL-GOV Dome 5MP 3.3-10.2mm IP66 IK10 IR GOV
Commercial Type No.: NDE-3703-AL-GOV | Product No.: F.01U.419.306
5 MP for highly detailed images
IVA Pro Buildings brings reliable deep-learning based detection of persons and vehicles
High Dynamic Range (HDR) to see every detail in both bright and dark areas of the scene
Built-in Secure Element with Trusted Platform Module (TPM) to ensure the highest level of security for device access and data transport
Built-in IR illuminator with up to 30 m (98 ft) viewing distance
Key Specifications
Built-in IR (ft) 98 ft
Built-in IR (m) 30 m
Frame rate (fps) 1 – 30 fps
Horizontal field of view (º) 101.4 – 30.1 °
Impact protection IK10
IP rating IP66
Lens focal length (mm) 3.3 – 10.2 mm
Operating temperature (°C) -30 – 50 °C
Operating temperature (°F) -22 – 122 °F
Sensor type 1/2.7 inch CMOS
Video compression H.264 (ISO/IEC 14496-10); M-JPEG; H.265/HEVC
Pendant pipe extension, 20" (50cm)
Commercial Type No. NDA-U-PMTE
Product No. F.01U.324.941
Extension for universal pipe mount, 50 cm, white
Pendant pipe mount, 4" (11 cm)
Commercial Type No. NDA-U-PMTS
Product No. F.01U.385.046
Universal pendant pipe mount for dome cameras, 11 cm (4"), white
Pole mount adapter small
Commercial Type No. NDA-U-PMAS
Product No. F.01U.324.943
Pole mount adapter small
Universal pole mount adapter, white; small.
Pendant wall/ceiling mount SMB
Commercial Type No. NDA-U-PSMB
Product No. F.01U.324.942
Surface mount box (SMB) for wall mount or pipe mount.
Pendant pipe mount, 12" (31cm)
Commercial Type No. NDA-U-PMT
Product No. F.01U.324.940
Universal pipe mount for dome cameras, 31 cm, white
Parts included with this product
Quantity Component
1 FLEXIDOME outdoor 3100i IR device
1 TR20 key
1 Mounting template
1 Quick installation guide
1 Safety and security information
3 Installer UX label
1 RJ45 guider
