HZC-363P-VR 36x Day/Night WDR Integrated Camera
High-intensity light industrial camera designed for petrochemical plants, cement factories, high-temperature furnaces, and kilns
Technical Specifications
Video Format: PAL
Image Sensor: 1/4" Sony Super HAD CCD
Effective Pixels: 752 (H) x 582 (V)
Horizontal Resolution: >520 TV Lines
Minimum Illumination: 0.1 lux
0.01 lux (TDN)
0.001 lux (Max Fields 512)
0.0001 lux (TDN, Max Fields 512)
Video Output: 1.0 Vp-p, 75 Ohms
Synchronization: Internal
Day/Night Conversion: True Day/Night
S/N Ratio: >50dB
AGC (Auto Gain Control): High / Medium / Low
Privacy Masking: On / Off (8 zones / selectable colors)
BLC Mode: Off / BLC / ABLC
Shutter Speed: 1/50 – 1/100,000 sec
Lens: f=3.4 ~ 122.4mm, F1.6 (Wide) ~ F4.5 (Tele)
Zoom: 36x Optical Zoom, 16x Digital Zoom (Total 576x)
White Balance: ATW / AWC / One Push / Indoor / Outdoor / MWB
High Light Compensation (HLC): On / Off (16 selectable zones, 5 selectable colors)
WDR (Wide Dynamic Range): On / Off
PIP (Picture-in-Picture): On / Off
Digital Noise Reduction: Off / Low / High
Control Interface: RS-422 / RS-485
Power Supply: DC 12V
Power Consumption: Max. 4.5W
Operating Temperature: -5℃ ~ 60℃ (-5℃ ~ 50℃ recommended)
Operating Humidity: 90% RH (non-condensing)
Dimensions (W x H x L): 62 x 71.6 x 116mm
Weight 510g
Protocols: ScanDome II, KD6, VCL, Pelco D/P
Certifications: CE/FCC
Features
1/4" Sony Super HAD CCD
36x optical zoom, 16x digital zoom (total 576x zoom)
520 TV lines horizontal resolution
True Day/Night (ICR), Wide Dynamic Range (WDR), BMB
Minimum illumination: 0.0001 Lux
Digital Noise Reduction (DNR), Picture-in-Picture (PiP), 36x optical zoom (max. 576x zoom)
Privacy masking, video motion detection
Built-in CDS sensor for precise filter control
