M118VG413IRCS Tamron DC Auto Iris CS CCTV Lens

SPECIFICATIONS

M118VG413IRCS
Imager Size 1/1.8
Mount Type CS
Focal Length 4.0  -  13mm
Aperture Range F/1.5  -  Close
Angle of View
(Horizontal x Vertical) 1/1.8 Wide 105.4°  x  77.6°
Tele 33.0°  x  24.8°
1/2 Wide 91.7°  x  67.9°
Tele 29.0°  x  21.8°
1/3 Wide 67.9°  x  50.6°
Tele 21.8°  x  16.3°
Focusing Range 0.3m  -  ∞
Operation Focus Manual with Lock
Zoom Manual with Lock
Iris DC Auto Iris
Back Focus(in air) 15.235mm(in air)
Wave Length Visible Light  -  Near Infrared
Operating Voltage Range Open 3.0V
Close 0.5V
Weight 172g
Operating Temperature -20°C  -  +60°C
