M13VG850IR Tamron DC Auto Iris CCTV Lens CS

Brand:Tamron

Model:M13VG850IR

lens:8-50mm

Detail

M13VG850IR Tamron DC Auto Iris CCTV Lens CS

SPECIFICATIONS

			M13VG850IR
Imager Size			1/3 (Applicable for 1/2.7 , 1/2.8)
Mount Type			CS
Focal Length			8 - 50mm
Aperture Length			F/1.6 - 360
Angle of View (Horizontal x Vertical)	1/3	Wide	33.5° x 25.1°
		Tele	5.6° x 4.2°
	1/4	Wide	25.1° x 18.8°
		Tele	4.2° x 3.2°
Focus Range			2m - ∞
Operation		Focus	Manual w / lock
		Zoom	Manual w / lock
		Iris	DC Auto Iris
Filter Size			-
Back Focus(in air)			8.08mm
Wave Length			Visible Light - Near Infrared
Operating Voltage			OPEN : 4.0v CLOSE : 0.5v
Driving Curret			95mA : Per-phase
Weight
Operation Temperature			-20°C - +60°C
Wiring Disgram
