SD530-PRE0 Pelco analog Camera
Product Features
• 30x Zoom Autofocus, Integrated Camera/Optics Packages
• Multiple models: Indoor In-Ceiling, Standard and Environmental Pendant,Pressurized and Stainless Steel Environmental Pendant
• Day/Night, 740 TVL, Wide Dynamic Range (WDR)
• Low Lux Noise Reduction
• Motion Detection
• Window Blanking, Horizontal and Zone Blanking
• Camera Title Overlay, 20 User-Definable Characters
• On-Screen Compass and Tilt Display
• Password Protection
• Built-in Surge and Limited Lightening Protection
• Integrated Passive Unshielded Twisted Pair (UTP) Circuit
• Internal Scheduling Clock
SYSTEM MODEL NUMBERS
Type Back Box Color Lower Dome Spectra V Series, 30X Day/Night (NTSC/PAL)
SD530-F0
SD530-PG-0
SD530-PG-1
SD530-PG-E0
SD530-PG-E1
SD530-PRE0
SD530-PRE1
SD530-PSGE1
COMPONENT MODEL NUMBERS
Back Box Dome Drive Lower Dome†
BB4-F In-ceiling, white
BB4-PG Pendant mount, grey
BB4-PG-E Pendant mount, grey, environmental
BB4-PR-E Pendant mount, environmental, pressurized, grey
BB4-PSG-E Pendant mount, stainless steel, grey
DD530 Day/Night (NTSC/PAL) camera (30X)
LDHQF-0 Smoked, surface, white
LDHQPB-0 Smoked, pendant, black
LDHQPB-1 Clear, pendant, black
LD53PR-0 Smoked, pressurized, black
 LD53PR-1 Clear, pressurized, black
 LD53PSB-1 Clear, stainless steel
 Notes: To order a fixed mount dome system, refer to the component models above and select one each of the following options: back box, dome drive, plus choice of lower dome.
